Kramer Vp2X2 Vga/Uxga/Audio Matrix Switcher

Name: Kramer Vp2X2 Vga/Uxga/Audio Matrix Switcher
Brand: KRAMER
SKU: Kramer Vp2X2

SKU: Kramer Vp2X2

Bu ürün proje / teklif kapsamındadır. Online fiyat gösterilmez — fiyat için teklif isteyin.

Paylaş:

Açıklama

The VP-2x2 is a high-performance matrix switcher for computer graphics video signals, with resolutions up to and exceeding UXGA, and balanced stereo audio signals. It can route either or both inputs to either or both outputs simultaneously.

High Bandwidth - 400MHz (-3dB) fully loaded.
HDTV Compatible.
Control - Front panel & RS-232 (K-Router™ Windows®-based Kramer software is included).
Front Panel Control Lockout.
Take Button - Executes multiple switches all at once.
Audio Breakaway Switching.

INPUTS:	2 VGA/UXGA on 15-pin HD (F) connectors; 2 balanced stereo audio on detachable terminal block connectors.
OUTPUTS:	2 VGA/UXGA on 15-pin HD (F) connectors; 2 balanced stereo audio on detachable terminal block connectors.
MAX. OUTPUT LEVEL:	Video: 1.7Vpp; audio: 7.2Vpp.
BANDWIDTH (-3dB):	Video: 400MHz; audio: 100kHz.
DIFF. GAIN:	0.05%.
DIFF. PHASE:	0.05Deg.
K-FACTOR:	0.05%.
S/N RATIO:	Video: 78.3dB; audio: 95dB, unweighted.
CROSSTALK:	Video: -43dB; audio: 77dB @1kHz.
CONTROLS:	Front panel buttons, RS-232.
COUPLING:	DC.
AUDIO THD + NOISE:	0.049%.
AUDIO 2nd HARMONIC:	0.003%.
POWER CONSUMPTION:	12V DC, 150mA.
DIMENSIONS:	22cm x 18cm x 4.5cm (8.7” x 7” x 1.7”) W, D, H.
WEIGHT:	1.1kg (2.4lbs) approx.
ACCESSORIES:	Power supply.
OPTIONS:	RK-1 19” rack adapter.
