Crown CDI 2/1200 Power Amplifikatör, 2x1200W/100V DSP, Network Kontrol

Crown CDI 2/1200 Power Amplifier
2x1200W/100V DSP, Network Kontrol



Feature Comparison

CDi DriveCore Model	Channels	Network Control	DSP	Control Port	BLU link
2|300	2
2|300BL	2
4|300	4
4|300BL	4
2|600	2
2|600BL	2
4|600	4
4|600BL	4
2|1200	2
2|1200BL	2
4|1200	4
4|1200BL	4



Output Power: Dual Mode - All Channels Driven

CDi DriveCore Model	Channels	2Ω	4Ω	8Ω	16Ω	70Vrms	100Vrms
2|300 / 2|300BL	2	150W	300W	300W	150W	300W	300W
4|300 / 4|300BL	4	150W	300W	300W	150W	300W	300W
2|600 / 2|600BL	2	300W	600W	600W	300W	600W	600W
4|600 / 4|600BL	4	300W	600W	600W	300W	600W	600W
2|1200 / 2|1200BL	2	850W	1200W	1200W	600W	1200W	1200W
4|1200 / 4|1200BL	4	850W	1200W	1200W	600W	1200W	1200W

Minimum Guaranteed Power (1kHz, all channels driven, max distortion 0.5%, duration 0.5 seconds, 120 - 240Vrms - 50/60Hz)



Output Power: Bridge Mono Mode - All Channels Driven

CDi DriveCore Model	4Ω	8Ω	16Ω	140Vrms	200Vrms
2|300 / 2|300BL	300W	600W	600W	600W	600W
4|300 / 4|300BL	300W	600W	600W	600W	600W
2|600 / 2|600BL	600W	1200W	1200W	1200W	1200W
4|600 / 4|600BL	600W	1200W	1200W	1200W	1200W
2|1200 / 2|1200BL	1200W	2400W	2400W	2400W	2400W
4|1200 / 4|1200BL	1200W	2400W	2400W	2400W	2400W

Minimum Guaranteed Power (1kHz, all channels driven, max distortion 0.5%, duration 0.5 seconds, 120 - 240Vrms - 50/60Hz)
